HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL3 SERIES

RL3-611/N-G-2-RE/BK-P5
ON-OFF 3P W/Lamp
RL3-611-G-2-WT/WT-P5
ON-OFF 2P
RL3-611-G-2-BK/BK-P5
ON-OFF 2P

SPECIFICATION:
(G) :6(2) A 250VAC T125 IE4
10A 125VAC
(H) :10(4)A 250VAC;6(4) A 250VAC 5E4
16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER

R L 3 - 6 -
1 1 / N
- G
- 2
- R E / B K
- P 5

|
|
|
|
|

Function
Current
Cap Printing
Cap/Housing Color
Terminal

Function
11
ON-OFF 2P
12
ON-OFF 3P
13
ON-OFF-ON 3P
11/N
ON-OFF
W/Lamp
Current
G
10A125VAC
6A250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
RE
Red
Terminal
Cap Printing
0
None
1
2
3
4
5
6 7 8
