HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL3 SERIES

RL3-4(S)-11-G-2-BK/BK-P8
ON-OFF 2P
RL3-4(S)-11-G-0-WT/BK-P8
ON-OFF 2P
RL3-4(S)-11-G-2-RE/BK-P8
ON-OFF 2P

SPECIFICATION:
(G) : 6(2) A 250VAC T125 1E4
10A 125VAC
(H) :10(4)A 250VAC;6(4) A 250VAC T125 IE4
16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER

R L 3 - 4 (S)-
11 / N
- G
- 2
- B K/ B K
- P 8

|
|
|
|
|

Function
Rating
Cap Printing
Cap/Housing Color
Terminal

Function
11
ON-OFF
2P
Current
G
10A 124VAC
6A 250VAC
H
16A 125VAC
12A 250VAC
Cap/Housing
Color
BK
Black
WT
White
GE
Grey
Terminal
Cap Printing
0
None
1
2
3
