RL3-2(D)-12/11-G-32-BK/BK-P16
ON-ON/ON-OFF 5P SPDT/SPST
RL3-2(D)-11(ON)11-31-BK/BK-P16
(ON)-OFF/ON-OFF 4P
PVC-CAP



SPECIFICATION:
(G) :  6(2) A 250VAC T125 1E4
      10A 125VAC
(H) :10(4)A 250VAC
     16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER


R L 3 - 2 (D)-
11/11
- G
- 30
- BK / B K
- P 5

|
|
|
|
|

Function
Rating
Cap Printing
Cap/Housing Color
Terminal

Function
11/11
ON-OFF/ON-OFF
12/11
ON-ON/ON-OFF
11(ON)/11
(ON)-OFF/ON-OFF
12/12
ON-ON/ON-ON
13/13
ON-OFF-ON/ON-OFF-ON
Current
G
10A125VAC
6A 250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
RE
Grey
GE
Red
BL
Blue
Terminal
Cap Printing
0
None
30
31
32
