RL3-221-G-2-BK/BK-P5
ON-OFF 4P DPST
RL2-323-G-6-BK/BK-P5
ON-OFF-ON 6P DPDT
PVC-CAP


SPECIFICATION:
(G) : 6(2) A 250VAC T125 1E4
      10A 125VAC
(H) :10(4)A 250VAC T125 1E4
     16A 125V/10A 250VAC 1/3HP 125-250VAC T105

EXPLANATION OF MODEL NUMBER


R L 3 - 2 -
2 1
- G
- 2
- BK / B K
- P 5

|
|
|
|
|

Function
Current
Cap Printing
Cap/Housing Color
Terminal

Function
21
ON-OFF
22
ON-ON
23
ON-OFF-ON
21(ON)
(ON)-OFF
21(OFF)
ON-(OFF)
22(ON)
ON-(ON)
Rating
G
10A125VAC
6A250VAC
H
16A125VAC
10A250VAC
Cap/Housing
Color
BK
Black
WT
White
GE
Grey
RE
Red
Terminal
Cap Printing
0
None
3
6
1
4
7
2
5
8
15
