HOMEPAGE >> PRODUCTS >> RLEIL ROCKER SWITCH >> RL2 SERIES

RL2-521/N-C-30-RE/BK-P2
ON-OFF 6P W/Lamp DPST
RL2-521/N-D-0-BK/BK-P2
ON-OFF 6P W/Round Len
RL2-521-P-0-WT/BK-P2
ON-OFF 4P W/PVC-CAP

SPECIFICATION:
16(4) A 250VAC T85
16(4) A 250VAC T125 1E4
16A 125V/8A 250VAC

EXPLANATION OF MODEL NUMBER

R L 2 - 5 -
2 1 / N
- C
- 30
- R E / B K
- P 1

|
|
|
|
|

Function
Cap Type
Cap Printing
Cap/Housing Color
Terminal

Function
21/N
ON-OFF 6P
W/Lamp
21
ON-OFF 4P
22
ON-ON 6P
Cap Type
A
Flat
C
Soft Line
P
W/PVC Cap
D
W/Round
Cap/Housing
Color
BK
Black
WT
White
RE
Red
GR
Green
OR
Orange
Terminal
Cap Printing
0
None
11
12
13
30
